一、Features:
1. Simple structure and convenient maintenance;
2. Significant energy saving effect, reducing the operating cost of the equipment;
3. There are two forms of packing seal and mechanical seal which are suitable for different shaft seal requirements. The packing box leakage coupling screw hole can deliver the dripping cooling liquid to the designated place to meeting the environmental requirements
4. There is no contact operation of the rotating parts of the compressor in the working chamber; the axial and radial loads are borne by different bearings respectively. The operation is stable, safe and reliable;
5. There are inspection holes on the side cover. As long as the inspection cover plate is opened, corrosion and scaling in the pump can be observed to facilitate equipment maintenance.
6. Due to the use of water or other liquid as working liquid, it is possible to carry away the heat of compression, the working process is close to isothermal compression, especially suitable for the extraction and pressing of inflammable and explosive gases, and gas and non-granular dust is allowed in the gas.
7. When the flow components of the compressor are made of corrosion-resistant materials, corrosive gases or corrosive liquids can be sucked as working fluids; The purchase cost can be reduced when ordinary materials are used and lined with macromolecular protective layer.
二、Model
Description:
2BEY101-2BD4-OY1450
2BEY--Liquid ring vacuum pump series code
101-Specification code
2-Range code
B-material code
D-Transmission code
4-Seal form code
0-Transmission mode additional code
Y-Auxiliary motor code
1450- rotating speed code
三、Spectrogram:
四、Application
field:
Power industry: condenser vacuum, negative pressure transport, desulphurization circulation device gypsum dehydration.
Coal industry: washing and selection vacuum dewatering, mine gas emissions, filtering equipment.
Food and beverage: vacuum packaging of food, vacuum freeze drying, beverage vacuum cans.
Mining metallurgy: cleaning and vacuum dehydration, filter matching.
Tobacco industry: cigarette machine negative pressure system, vacuum moisture return system.
Petrochemical industry: filtration, pressure swing adsorption, decarburizations, hydrogen extraction, oxygen production, purification, vacuum distillation, vacuum crystallization, pressure transmission flammable, explosive gas.
Sugar industry: pressure delivery of CO2 gas.
